The star connected motor in this case is then mathematically the delta connected motors equivalent star connection.

Pdf star delta motor control. The connection of a three phase induction motor with a star delta starter is shown in the figure below. The control circuit consists of push button switches auxiliary contacts and a timer. All about motors page motor protection 8 3 notes on engineering 8 15 circuit documents 8 19 power supply 8 21 control circuit supply 8 24 contactor markings 8 25 direct on line start of three phase motors 8 26 control circuit devices for direct on line start 8 34 star delta switching of three phase motors 8 35. This starter is mostly used for less than 5 kw rating motors.

The first is that of a delta connected motor compared to a star connected motor of the same power and voltage ratings. Pack contactorcontactor series ck star delta starters. In this tutorial we will show the star delta y d 3 phase induction ac motor starting method by automatic star delta starter with timer with schematic power control and wiring diagram as well as how star delta starter works and their applications with advantages and disadvantages. Two comparisons are considered.

Dol is used for controlling this high starting current to the motor. Star delta. Star delta starter figure is. Star delta starter is a very common method for starting an induction motor.

For star delta starterthe basic function is to enable the motor to start and the motor windings are configured in a star formation to the supply voltage. The voltage applied for star delta starter to the individual motor winding is therefore reduced by a factor of 13 058 this connection amounts to approximately 30 of the delta values. Ip00 cl00wkle00 103238 1 cl01 cl02 wkle02 103241 1 cl25wkle25 103243 1 metallic plate cl06 cl07 cl08 wlsd 103247 1 cl09 cl10 wlsd1 241750 1 busbar sets for power circuit series cl star delta starters plate plate. Motor being star or delta connected when supplied by a current source inverter.

A star delta is used for a cage motor designed to run normally on the delta connected stator winding. Controlling the interchanging star connection and delta connection of an ac induction motor is achieved by means of a star delta or wye delta control circuit.
